Multiquip 2076 Tube Pivot - OEM Replacement Part for Trowel Spider Assembly

The pivot tube serves as a critical linkage component in the trowel spider assembly, connecting the stabilizer system to the trowel arms and enabling proper blade pitch control during concrete finishing operations. This component works in conjunction with the universal spider kit, stabilizer lever, and spider arm bushings to maintain precise blade angle adjustments and ensure flat, even finishing across the concrete surface.

In trowel maintenance procedures, the pivot tube must be inspected during spider assembly service intervals. According to Multiquip technical documentation, proper trowel arm pitch adjustment is critical for maintaining flatness tolerances—typically within 0.004 inches (0.10 mm) across all six sides of the trowel arm hex section. A worn or damaged pivot tube can compromise pitch control, leading to uneven blade pressure, inconsistent concrete finish quality, and premature wear on spider assembly components. This part is essential for both walk-behind and ride-on trowel configurations that utilize the stabilizer arm system.

Compatible with the following Multiquip trowel models:

• BRT Series
• BTO20HTCSL
• JRT Series
• JTNS20-SW20
• JTNSW20-JTNSW24
• JWN24HTCSL

Genuine Multiquip OEM part, sold by an authorized dealer.
