Multiquip 2775 Wire Frame Harness - OEM Replacement Part for Trowels

The wire frame harness serves as the critical electrical distribution component connecting the main harness to the pitch control system on Multiquip power trowels. This harness routes power from the fuse and relay box to the left and right pitch actuators, utilizing 12 AWG and 14 AWG wiring to handle the electrical load required for precise blade pitch adjustment during troweling operations.

This frame harness integrates with the main harness system through DTP06-2S and DTP06-4S connectors, linking to the DT04-4P connector on the pitch actuators. The harness includes critical splice connections—Z6/Z8 for left-hand pitch power (14 AWG red/orange) and Z7/Z9 for right-hand pitch power (14 AWG red/green)—ensuring dedicated power delivery to each actuator. The design incorporates ground connections through 12 AWG black wiring and ties into terminals T2, T3, and T6 on the bus bar assembly.

Compatible with the following Multiquip power trowel models:

• BHN Series
• BRT Series
• BTO20HTCSL
• HRT Series

Genuine Multiquip OEM part, sold by an authorized dealer.
