Multiquip 2824 Tube Control Pivot 1" JRN - OEM Replacement Part

The control pivot tube is a critical mechanical linkage component that connects the operator's steering controls to the trowel arm assemblies on ride-on power trowels. This 1-inch journal tube enables precise directional control and trowel arm positioning during concrete finishing operations. When this pivot tube shows signs of wear, excessive play, or binding, operators will experience reduced steering responsiveness and difficulty maintaining proper blade pitch during floating and finishing work.

This tube control pivot is part of the trowel arm control system detailed in the JWN Series maintenance procedures. The trowel arm assemblies require precise adjustment using the specialized fixture (P/N 9177) to maintain the critical 0.010-inch clearance specification between adjustment components. A worn or damaged control pivot tube will compromise these adjustments and can lead to uneven blade pitch, resulting in poor concrete finish quality. Regular inspection of all pivot points and control linkages is essential to prevent damage from rough handling or impacts with exposed plumbing and forms during operation.

Compatible with the following Multiquip models:

• JWN24HTCSL

Genuine Multiquip OEM part, sold by an authorized dealer.
