Multiquip 9150 Spider Assembly 4-Blade Left Hand HD48 - OEM Replacement Part

The spider assembly is the critical hub that connects the gearbox output shaft to the trowel blades, transmitting rotational power to achieve consistent concrete finishing. This heavy-duty 4-blade left-hand configuration mounts directly to the vertical gearbox shaft via a cone point square head set screw and jam nut arrangement. The spider features four radial arms extending outward where trowel blades attach using bolts and lock washers.

This spider assembly is essential for maintaining proper trowel performance. Common failure symptoms requiring replacement include trowel bouncing, uneven swirls in concrete, wobbling during operation, or bent trowel arms that cannot be straightened. The spider arm fit must be precise to prevent pitch adjustment issues and ensure all blades maintain the same angle. Worn spider bushings or bent arms compromise the lower wear plate alignment, creating a "dished" effect on finished concrete rather than the flat surface required for quality work.

During installation, place the trowel on a flat surface with blocks under the main guard ring for support. A light tap with a rubber mallet may be necessary to properly seat the spider onto the gearbox main shaft. Clean all concrete and debris from trowel arms with a wire brush before blade attachment to ensure proper seating.

Compatible models:

• HDA-SERIES Walk-Behind Trowels
• HRT Series

Genuine Multiquip OEM part, sold by an authorized dealer.
