Multiquip 11142 Rod End 1/2-20 Male RH - OEM Replacement Part

This rod end connects the trowel arm adjustment bolt to the fixture lever assembly, enabling precise blade pitch adjustment on Multiquip power trowels. The 1/2-20 male right-hand thread configuration allows for fine-tuned adjustment of trowel arm positioning, which is critical for maintaining the .010-inch clearance specification between the adjustment bolt and fixture bolt during blade pitch calibration procedures.

During trowel arm maintenance, this rod end works in conjunction with the locking nut to secure the adjustment bolt position after trowel arms have been placed in the fixture channel and aligned. Proper adjustment ensures all trowel blades rotate in smooth, fluid motion without pulling harder on one side. Technicians should verify this component shows no thread wear or binding when performing routine trowel arm inspections, particularly after suspected damage from dropping the trowel on pads or striking exposed rebar, plumbing, or forms during operation.

Compatible with the following Multiquip models:

• EHHNK5
• HHN-34TVD
• HHNG4
• HTN27KTCSL
• HTNS5S-2
• JWN24HTCSL
• STX55J6

Genuine Multiquip OEM part, sold by an authorized dealer.
