Multiquip 1717 Screw Adjusting Assembly (QP) - OEM Replacement Part for Trowels

The screw adjusting assembly is a critical component used to calibrate trowel arm pitch on walk-behind and ride-on power trowels. This adjustment bolt works with the trowel arm adjustment fixture to ensure consistent blade angle across all arms, maintaining a flat and evenly pitched finishing surface. Proper adjustment is essential for achieving smooth concrete finishes and preventing uneven wear on trowel blades.

During trowel arm adjustment procedures, this screw is set to a precise distance using calipers—typically ranging from 0.15 inches to 0.25 inches depending on the trowel series. The adjustment bolt contacts a stop on the adjustment fixture, allowing technicians to calibrate all trowel arms to the same specification. This ensures the finisher remains as flat and evenly pitched as possible during operation. The locking nut secures the adjustment once the correct distance is achieved.

Compatible with the following Multiquip trowel models:

• B46
• BH90C
• HDA-SERIES
• J36
• JH55C

Genuine Multiquip OEM part, sold by an authorized dealer.
