Wacker Neuson AR26 External Vibrator
The parts bench
Need the PDF? ↓Page 8 — External vibrator cpl.
Parts list — exactly as printed22 rows
| No. | Part No. | Part Name | Qty | Remarks | |
|---|---|---|---|---|---|
| 3 | 5100003631 | Shim | 1 | PARTS REQUEST | |
|
COMING Shim
5100003631 · qty on machine: 1 | |||||
| 4 | 5100004449 | Grooved ball bearing | 2 | PARTS REQUEST | |
|
COMING Grooved ball bearing
5100004449 · qty on machine: 2 | |||||
| 5 | 5100003117 | Bearing bracket | 2 | PARTS REQUEST | |
|
COMING Bearing bracket
5100003117 · qty on machine: 2 | |||||
| 6 | 5000033351 | Hexagon nut | 4 | M14 x 1,5 | ISO8675 | PARTS REQUEST |
|
COMING Hexagon nut
5000033351 · qty on machine: 4 M14 x 1,5 | ISO8675 | |||||
| 7 | 5000127791 | Eccentric weight | 16 | PARTS REQUEST | |
|
COMING Eccentric weight
5000127791 · qty on machine: 16 | |||||
| 9 | 5100002201 | O-ring | 2 | PARTS REQUEST | |
|
COMING O-ring
5100002201 · qty on machine: 2 | |||||
| 10 | 5100001529 | Cover | 2 | PARTS REQUEST | |
|
COMING Cover
5100001529 · qty on machine: 2 | |||||
| 11 | 5000095509 | Cheese head screw | 8 | M5 x 12 2.6Nm/2ft.lbs | DIN6912 | ADD TO CART |
| 12 | 5100003624 | Power supply cable with plug | 1 | PARTS REQUEST | |
|
COMING Power supply cable with plug
5100003624 · qty on machine: 1 | |||||
| 13 | 5100042134 | Cable bushing | 1 | PARTS REQUEST | |
|
COMING Cable bushing
5100042134 · qty on machine: 1 | |||||
| 14 | 5100002084 | Screw connection | 1 | PARTS REQUEST | |
|
COMING Screw connection
5100002084 · qty on machine: 1 | |||||
| 15 | 5000106220 | Clamp | 1 | PARTS REQUEST | |
|
COMING Clamp
5000106220 · qty on machine: 1 | |||||
| 16 | 5000209458 | Disc | 3 | PARTS REQUEST | |
|
COMING Disc
5000209458 · qty on machine: 3 | |||||
| 17 | 5000010872 | Hexagon nut | 3 | PARTS REQUEST | |
|
COMING Hexagon nut
5000010872 · qty on machine: 3 | |||||
| 18 | 5100003596 | Gasket | 1 | PARTS REQUEST | |
|
COMING Gasket
5100003596 · qty on machine: 1 | |||||
| 19 | 5100003534 | Cover | 1 | PARTS REQUEST | |
|
COMING Cover
5100003534 · qty on machine: 1 | |||||
| 20 | 5000200931 | Countersunk screw | 4 | M5 x 10 | ISO10642 | ADD TO CART |
| 22 | 5000219173 | Labels | 1 | PARTS REQUEST | |
|
COMING Labels
5000219173 · qty on machine: 1 | |||||
| 29 | 5100042029 | Spacer | 1 | PARTS REQUEST | |
|
COMING Spacer
5100042029 · qty on machine: 1 | |||||
| 31 | 5100045462 | Decal proposition 65 | 1 | PARTS REQUEST | |
|
COMING Decal proposition 65
5100045462 · qty on machine: 1 | |||||
| 5000010621 | Flat washer | 4 | ADD TO CART | ||
| 2 | 5100003121 | Motor armature cpl. | 1 | COMPLETE ASSEMBLY (cpl.) | PARTS REQUEST |
|
COMING Motor armature cpl.
5100003121 · qty on machine: 1 COMPLETE ASSEMBLY (cpl.) | |||||
Page 10 — Accessories - fastening clamp sv4
Parts list — exactly as printed9 rows
| No. | Part No. | Part Name | Qty | Remarks | |
|---|---|---|---|---|---|
| 1 | 5000201173 | Fastening clamp | 1 | PARTS REQUEST | |
|
COMING Fastening clamp
5000201173 · qty on machine: 1 | |||||
| 5 | 5000128144 | Nut | 1 | PARTS REQUEST | |
|
COMING Nut
5000128144 · qty on machine: 1 | |||||
| 6 | 5000208842 | Collar | 1 | PARTS REQUEST | |
|
COMING Collar
5000208842 · qty on machine: 1 | |||||
| 7 | 5000202934 | Cup spring | 8 | 35,5-2 | DIN2093 | PARTS REQUEST |
|
COMING Cup spring
5000202934 · qty on machine: 8 35,5-2 | DIN2093 | |||||
| 9 | 5000011438 | Hexagonal head cap screw | 4 | 49Nm/36ft.lbs | DIN933 | ADD TO CART |
| 10 | 5000010883 | Hexagon nut | 4 | ADD TO CART | |
| 15 | 5000212026 | Safety belt cpl. | 1 | COMPLETE ASSEMBLY (cpl.) | PARTS REQUEST |
|
COMING Safety belt cpl.
5000212026 · qty on machine: 1 COMPLETE ASSEMBLY (cpl.) | |||||
| 16 | 5000010621 | Flat washer | 4 | ADD TO CART | |
| 18 | 5000203980 | Fixing set | 1 | PARTS REQUEST | |
|
COMING Fixing set
5000203980 · qty on machine: 1 | |||||
Page 12 — Wrench
Parts list — exactly as printed1 rows
| No. | Part No. | Part Name | Qty | Remarks | |
|---|---|---|---|---|---|
| 1 | 5000201936 | Wrench | 1 | PARTS REQUEST | |
|
COMING Wrench
5000201936 · qty on machine: 1 | |||||
Page 14 — AR 26/6/042 3,5kN Clamping Bracket SV 5
Parts list — exactly as printed9 rows
| No. | Part No. | Part Name | Qty | Remarks | |
|---|---|---|---|---|---|
| 1 | 5000202910 | Fastening clamp | 1 | PARTS REQUEST | |
|
COMING Fastening clamp
5000202910 · qty on machine: 1 | |||||
| 5 | 5000128144 | Nut | 1 | PARTS REQUEST | |
|
COMING Nut
5000128144 · qty on machine: 1 | |||||
| 6 | 5000201167 | Sleeve | 1 | PARTS REQUEST | |
|
COMING Sleeve
5000201167 · qty on machine: 1 | |||||
| 7 | 5000202934 | Cup spring | 8 | 35,5-2 | DIN2093 | PARTS REQUEST |
|
COMING Cup spring
5000202934 · qty on machine: 8 35,5-2 | DIN2093 | |||||
| 9 | 5000011438 | Hexagonal head cap screw | 4 | 49Nm/36ft.lbs | DIN933 | ADD TO CART |
| 10 | 5000010883 | Hexagon nut | 4 | ADD TO CART | |
| 15 | 5000212026 | Safety belt cpl. | 1 | COMPLETE ASSEMBLY (cpl.) | PARTS REQUEST |
|
COMING Safety belt cpl.
5000212026 · qty on machine: 1 COMPLETE ASSEMBLY (cpl.) | |||||
| 17 | 5000010621 | Flat washer | 4 | ADD TO CART | |
| 18 | 5000203980 | Fixing set | 1 | PARTS REQUEST | |
|
COMING Fixing set
5000203980 · qty on machine: 1 | |||||
Page 16 — AR 26/6/042 3,5kN Mounting Plate
Parts list — exactly as printed1 rows
| No. | Part No. | Part Name | Qty | Remarks | |
|---|---|---|---|---|---|
| 1 | 5000206613 | Plate | 1 | PARTS REQUEST | |
|
COMING Plate
5000206613 · qty on machine: 1 | |||||
Page 18 — AR 26/6/042 3,5kN Clamping Device SV 51
Parts list — exactly as printed7 rows
| No. | Part No. | Part Name | Qty | Remarks | |
|---|---|---|---|---|---|
| 1 | 5000205044 | Clamping device sv 51 | 1 | PARTS REQUEST | |
|
COMING Clamping device sv 51
5000205044 · qty on machine: 1 | |||||
| 4 | 5000202934 | Cup spring | 8 | 35,5-2 | DIN2093 | PARTS REQUEST |
|
COMING Cup spring
5000202934 · qty on machine: 8 35,5-2 | DIN2093 | |||||
| 5 | 5000128144 | Nut | 2 | PARTS REQUEST | |
|
COMING Nut
5000128144 · qty on machine: 2 | |||||
| 7 | 5000206837 | Countersunk bolt | 4 | M10x 40 | ISO10642 | ADD TO CART |
| 8 | 5000017313 | Hexagon nut | 4 | ADD TO CART | |
| 11 | 5000212026 | Safety belt cpl. | 1 | COMPLETE ASSEMBLY (cpl.) | PARTS REQUEST |
|
COMING Safety belt cpl.
5000212026 · qty on machine: 1 COMPLETE ASSEMBLY (cpl.) | |||||
| 14 | 5000010621 | Flat washer | 4 | ADD TO CART | |
Page 20 — AR 26/6/042 3,5kN Clamping Device SV 41
Parts list — exactly as printed4 rows
| No. | Part No. | Part Name | Qty | Remarks | |
|---|---|---|---|---|---|
| 8 | 5000212026 | Safety belt cpl. | 1 | COMPLETE ASSEMBLY (cpl.) | PARTS REQUEST |
|
COMING Safety belt cpl.
5000212026 · qty on machine: 1 COMPLETE ASSEMBLY (cpl.) | |||||
| 1 | 5000205524 | Clamping device sv 41 | 1 | PARTS REQUEST | |
|
COMING Clamping device sv 41
5000205524 · qty on machine: 1 | |||||
| 3 | 5000011326 | Hexagonal head cap screw | 4 | M10 x 80 49Nm/36ft.lbs | DIN931 | PARTS REQUEST |
|
COMING Hexagonal head cap screw
5000011326 · qty on machine: 4 M10 x 80
49Nm/36ft.lbs | DIN931 | |||||
| 4 | 5000010621 | Flat washer | 4 | ADD TO CART | |
Page 22 — AR 26/6/042 3,5kN Clamping Bracket SV 4 L
Parts list — exactly as printed9 rows
| No. | Part No. | Part Name | Qty | Remarks | |
|---|---|---|---|---|---|
| 7 | 5000201167 | Sleeve | 1 | PARTS REQUEST | |
|
COMING Sleeve
5000201167 · qty on machine: 1 | |||||
| 8 | 5000202934 | Cup spring | 8 | 35,5-2 | DIN2093 | PARTS REQUEST |
|
COMING Cup spring
5000202934 · qty on machine: 8 35,5-2 | DIN2093 | |||||
| 9 | 5000128144 | Nut | 1 | PARTS REQUEST | |
|
COMING Nut
5000128144 · qty on machine: 1 | |||||
| 10 | 5000011438 | Hexagonal head cap screw | 4 | 49Nm/36ft.lbs | DIN933 | ADD TO CART |
| 11 | 5000010883 | Hexagon nut | 4 | ADD TO CART | |
| 16 | 5000212026 | Safety belt cpl. | 1 | COMPLETE ASSEMBLY (cpl.) | PARTS REQUEST |
|
COMING Safety belt cpl.
5000212026 · qty on machine: 1 COMPLETE ASSEMBLY (cpl.) | |||||
| 17 | 5000010621 | Flat washer | 4 | ADD TO CART | |
| 18 | 5000203980 | Fixing set | 1 | PARTS REQUEST | |
|
COMING Fixing set
5000203980 · qty on machine: 1 | |||||
| 1 | 5000206720 | Fastening clamp sv 4 l | 1 | PARTS REQUEST | |
|
COMING Fastening clamp sv 4 l
5000206720 · qty on machine: 1 | |||||
Page 24 — AR 26/6/042 3,5kN Clamping Device SV 54
Parts list — exactly as printed5 rows
| No. | Part No. | Part Name | Qty | Remarks | |
|---|---|---|---|---|---|
| 1 | 5000211422 | Clamping device sv 54 | 1 | PARTS REQUEST | |
|
COMING Clamping device sv 54
5000211422 · qty on machine: 1 | |||||
| 2 | 5000212026 | Safety belt cpl. | 1 | COMPLETE ASSEMBLY (cpl.) | PARTS REQUEST |
|
COMING Safety belt cpl.
5000212026 · qty on machine: 1 COMPLETE ASSEMBLY (cpl.) | |||||
| 3 | 5000206837 | Countersunk bolt | 4 | M10x 40 | ISO10642 | ADD TO CART |
| 4 | 5000017313 | Hexagon nut | 4 | ADD TO CART | |
| 14 | 5000010621 | Flat washer | 4 | ADD TO CART | |
Page 26 — AR 26/6/042 3,5kN Clamping Device SV 52
Parts list — exactly as printed6 rows
| No. | Part No. | Part Name | Qty | Remarks | |
|---|---|---|---|---|---|
| 4 | 5000010883 | Hexagon nut | 4 | ADD TO CART | |
| 5 | 5000212026 | Safety belt cpl. | 1 | COMPLETE ASSEMBLY (cpl.) | PARTS REQUEST |
|
COMING Safety belt cpl.
5000212026 · qty on machine: 1 COMPLETE ASSEMBLY (cpl.) | |||||
| 14 | 5000010621 | Flat washer | 4 | ADD TO CART | |
| 1 | 5000210410 | Clamping device sv 52 | 1 | PARTS REQUEST | |
|
COMING Clamping device sv 52
5000210410 · qty on machine: 1 | |||||
| 2 | 5000210419 | Clip nut | 1 | PARTS REQUEST | |
|
COMING Clip nut
5000210419 · qty on machine: 1 | |||||
| 3 | 5000011438 | Hexagonal head cap screw | 4 | 49Nm/36ft.lbs | DIN933 | ADD TO CART |
Page 28 — AR 26/6/042 3,5kN Clamping Device SV 6
Parts list — exactly as printed6 rows
| No. | Part No. | Part Name | Qty | Remarks | |
|---|---|---|---|---|---|
| 2 | 5000218140 | Attachment adapter | 1 | PARTS REQUEST | |
|
COMING Attachment adapter
5000218140 · qty on machine: 1 | |||||
| 3 | 5000218138 | Base plate | 1 | PARTS REQUEST | |
|
COMING Base plate
5000218138 · qty on machine: 1 | |||||
| 4 | 5000211885 | Clip nut | 2 | PARTS REQUEST | |
|
COMING Clip nut
5000211885 · qty on machine: 2 | |||||
| 5 | 5000017313 | Hexagon nut | 4 | ADD TO CART | |
| 6 | 5000212026 | Safety belt cpl. | 1 | COMPLETE ASSEMBLY (cpl.) | PARTS REQUEST |
|
COMING Safety belt cpl.
5000212026 · qty on machine: 1 COMPLETE ASSEMBLY (cpl.) | |||||
| 7 | 5000010621 | Flat washer | 4 | ADD TO CART | |
Page 30 — AR 26/6/042 3,5kN Clamping Device SV 46
Parts list — exactly as printed8 rows
| No. | Part No. | Part Name | Qty | Remarks | |
|---|---|---|---|---|---|
| 6 | 5000017313 | Hexagon nut | 4 | ADD TO CART | |
| 7 | 5000212026 | Safety belt cpl. | 1 | COMPLETE ASSEMBLY (cpl.) | PARTS REQUEST |
|
COMING Safety belt cpl.
5000212026 · qty on machine: 1 COMPLETE ASSEMBLY (cpl.) | |||||
| 8 | 5000207193 | Angle cpl. | 2 | COMPLETE ASSEMBLY (cpl.) | PARTS REQUEST |
|
COMING Angle cpl.
5000207193 · qty on machine: 2 COMPLETE ASSEMBLY (cpl.) | |||||
| 9 | 5000011324 | Hexagonal head cap screw | 4 | M10 x 70 49Nm/36ft.lbs | DIN931 | PARTS REQUEST |
|
COMING Hexagonal head cap screw
5000011324 · qty on machine: 4 M10 x 70
49Nm/36ft.lbs | DIN931 | |||||
| 10 | 5000010621 | Flat washer | 4 | ADD TO CART | |
| 3 | 5000218140 | Attachment adapter | 1 | PARTS REQUEST | |
|
COMING Attachment adapter
5000218140 · qty on machine: 1 | |||||
| 4 | 5000218139 | Base plate | 1 | PARTS REQUEST | |
|
COMING Base plate
5000218139 · qty on machine: 1 | |||||
| 5 | 5000211885 | Clip nut | 2 | PARTS REQUEST | |
|
COMING Clip nut
5000211885 · qty on machine: 2 | |||||
Page 32 — AR 26/6/042 3,5kN Clamping Bracket SV55
Parts list — exactly as printed8 rows
| No. | Part No. | Part Name | Qty | Remarks | |
|---|---|---|---|---|---|
| 6 | 5000010883 | Hexagon nut | 4 | ADD TO CART | |
| 7 | 5000212026 | Safety belt cpl. | 1 | COMPLETE ASSEMBLY (cpl.) | PARTS REQUEST |
|
COMING Safety belt cpl.
5000212026 · qty on machine: 1 COMPLETE ASSEMBLY (cpl.) | |||||
| 8 | 5000010621 | Flat washer | 4 | ADD TO CART | |
| 1 | 5000211925 | Fastening clamp sv55 | 1 | PARTS REQUEST | |
|
COMING Fastening clamp sv55
5000211925 · qty on machine: 1 | |||||
| 2 | 5000128144 | Nut | 1 | PARTS REQUEST | |
|
COMING Nut
5000128144 · qty on machine: 1 | |||||
| 3 | 5000201167 | Sleeve | 1 | PARTS REQUEST | |
|
COMING Sleeve
5000201167 · qty on machine: 1 | |||||
| 4 | 5000202934 | Cup spring | 8 | 35,5-2 | DIN2093 | PARTS REQUEST |
|
COMING Cup spring
5000202934 · qty on machine: 8 35,5-2 | DIN2093 | |||||
| 5 | 5000011438 | Hexagonal head cap screw | 4 | 49Nm/36ft.lbs | DIN933 | ADD TO CART |
Page 34 — AR 26/6/042 3,5kN Clamping Device SV 43
Parts list — exactly as printed6 rows
| No. | Part No. | Part Name | Qty | Remarks | |
|---|---|---|---|---|---|
| 1 | 5000211419 | Plate | 1 | PARTS REQUEST | |
|
COMING Plate
5000211419 · qty on machine: 1 | |||||
| 2 | 5000211420 | Angle | 2 | PARTS REQUEST | |
|
COMING Angle
5000211420 · qty on machine: 2 | |||||
| 3 | 5000011329 | Hexagonal head cap screw | 4 | M10 x 100 49Nm/36ft.lbs | ISO4014 | PARTS REQUEST |
|
COMING Hexagonal head cap screw
5000011329 · qty on machine: 4 M10 x 100
49Nm/36ft.lbs | ISO4014 | |||||
| 4 | 5000010621 | Flat washer | 4 | ADD TO CART | |
| 5 | 5000212026 | Safety belt cpl. | 1 | COMPLETE ASSEMBLY (cpl.) | PARTS REQUEST |
|
COMING Safety belt cpl.
5000212026 · qty on machine: 1 COMPLETE ASSEMBLY (cpl.) | |||||
| 6 | 5000211418 | Clamping device sv43 | 1 | PARTS REQUEST | |
|
COMING Clamping device sv43
5000211418 · qty on machine: 1 | |||||
Page 36 — AR 26/6/042 3,5kN Clamping Bracket SV 53
Parts list — exactly as printed11 rows
| No. | Part No. | Part Name | Qty | Remarks | |
|---|---|---|---|---|---|
| 9 | 5000212026 | Safety belt cpl. | 1 | COMPLETE ASSEMBLY (cpl.) | PARTS REQUEST |
|
COMING Safety belt cpl.
5000212026 · qty on machine: 1 COMPLETE ASSEMBLY (cpl.) | |||||
| 10 | 5000011438 | Hexagonal head cap screw | 4 | 49Nm/36ft.lbs | DIN933 | ADD TO CART |
| 11 | 5000010883 | Hexagon nut | 4 | ADD TO CART | |
| 14 | 5000010621 | Flat washer | 4 | ADD TO CART | |
| 1 | 5000215068 | Clamping block | 2 | PARTS REQUEST | |
|
COMING Clamping block
5000215068 · qty on machine: 2 | |||||
| 2 | 5000219199 | Bolt | 2 | PARTS REQUEST | |
|
COMING Bolt
5000219199 · qty on machine: 2 | |||||
| 3 | 5000202934 | Cup spring | 8 | 35,5-2 | DIN2093 | PARTS REQUEST |
|
COMING Cup spring
5000202934 · qty on machine: 8 35,5-2 | DIN2093 | |||||
| 4 | 5000128144 | Nut | 1 | PARTS REQUEST | |
|
COMING Nut
5000128144 · qty on machine: 1 | |||||
| 5 | 5100079947 | Bolt | 2 | PARTS REQUEST | |
|
COMING Bolt
5100079947 · qty on machine: 2 | |||||
| 6 | 5000213069 | Locking pin | 2 | PARTS REQUEST | |
|
COMING Locking pin
5000213069 · qty on machine: 2 | |||||
| 8 | 5000213070 | Fastening clamp sv 53 | 1 | PARTS REQUEST | |
|
COMING Fastening clamp sv 53
5000213070 · qty on machine: 1 | |||||
Page 38 — Cable bushing
Parts list — exactly as printed1 rows
| No. | Part No. | Part Name | Qty | Remarks | |
|---|---|---|---|---|---|
| 1 | 5100043358 | Cable bushing | 1 | PARTS REQUEST | |
|
COMING Cable bushing
5100043358 · qty on machine: 1 | |||||
The machine itself
Machine
Engine
Wacker Neuson AR26 external vibrator.
List price: $1,495.00
Keep-it-running spares
All listed parts →Every part that fits this machine
5000010621
Flat washer
$0.95
5000010872
Hexagon nut
5000010883
Hexagon nut
$0.95
5000011324
Hexagonal head cap screw
5000011326
Hexagonal head cap screw
5000011329
Hexagonal head cap screw
5000011438
Hexagonal head cap screw
$0.95
5000017313
Hexagon nut
$0.95
5000033351
Hexagon nut
5000095509
Cheese head screw
$0.95
5000106220
Clamp
5000127791
Eccentric weight
5000128144
Nut
5000200931
Countersunk screw
$0.95
5000201167
Sleeve
5000201173
Fastening clamp
5000201936
Wrench
5000202910
Fastening clamp
5000202934
Cup spring
5000203980
Fixing set
5000205044
Clamping device sv 51
5000205524
Clamping device sv 41
5000206613
Plate
5000206720
Fastening clamp sv 4 l
5000206837
Countersunk bolt
$1.95
5000207193
Angle cpl.
5000208842
Collar
5000209458
Disc
5000210410
Clamping device sv 52
5000210419
Clip nut
5000211418
Clamping device sv43
5000211419
Plate
5000211420
Angle
5000211422
Clamping device sv 54
5000211885
Clip nut
5000211925
Fastening clamp sv55
5000212026
Safety belt cpl.
5000213069
Locking pin
5000213070
Fastening clamp sv 53
5000215068
Clamping block
5000218138
Base plate
5000218139
Base plate
5000218140
Attachment adapter
5000219173
Labels
5000219199
Bolt
5100001529
Cover
5100002084
Screw connection
5100002201
O-ring
5100003117
Bearing bracket
5100003121
Motor armature cpl.
5100003534
Cover
5100003596
Gasket
5100003624
Power supply cable with plug
5100003631
Shim
5100004449
Grooved ball bearing
5100042029
Spacer
5100042134
Cable bushing
5100043358
Cable bushing
5100045462
Decal proposition 65
5100079947
Bolt
Service notices & part changes
Take the factory book with you
The interactive diagram above stays open for everyone. No email wall on the good stuff. The full factory PDF pack is for the shop laptop and the glovebox.
From the guides desk
A
Chat with ARIA
Ask ARIA about your machine.
Scoped to this machine: fitment checks, torque and oil answers, part lookups from the manual behind this page.
