Available to order.
This M8-1.25 x 40MM flat head socket cap screw provides a secure, flush-mount fastening point on reversible plate compactor assemblies, making it an essential hardware component for technicians performing structural repairs or scheduled maintenance on Bartell equipment.
The FHSCS (Flat Head Socket Cap Screw) designation indicates a countersunk head design driven by a hex socket key, allowing the fastener to sit flush with the mating surface. This profile is commonly used in applications where a protruding bolt head would interfere with moving components, guard panels, or ground-contact surfaces, all common design considerations on reversible plate compactors. The M8-1.25 thread specification refers to an 8mm nominal diameter with a 1.25mm thread pitch, conforming to standard metric coarse thread dimensions. The 40mm length ensures adequate thread engagement through the host material while maintaining proper clamp load across the joint.
Replacing worn, stripped, or corroded fasteners with the correct OEM-spec hardware is critical to maintaining the structural integrity and safe operation of compaction equipment. Using an incorrect fastener, wrong length, pitch, or head type, can result in joint failure, misalignment of assemblies, or damage to mating components.
Compatible models include:
- Bartell BR5100 Reversible Plate Compactor
Genuine Bartell Global OEM part, sold by an authorized dealer.
