Available to order.
Serving as the critical interface between the grinding wheels and the planetary drive system, the tooling plate secures and aligns grinding tooling on Bartell Predator planetary grinders, making it an essential component for maintaining consistent surface contact, balanced rotation, and effective material removal. When a tooling plate becomes worn, cracked, or damaged, operators will notice uneven grinding patterns, excessive vibration, and degraded finish quality across the work surface.
According to the official Bartell Global Y Grinder assembly documentation (OIPB-I02003), part number 35004 is specified as a direct assembly component of the P750Y grinder, with three units installed per machine. This quantity is significant: all three tooling plates should be inspected together and replaced as a set whenever wear or damage is detected on any single plate, ensuring balanced load distribution across all planetary heads and preventing premature stress on the drive system.
This part is categorized under the Predator Planetary Grinder line and is compatible with the following models:
As a high-wear contact component, the tooling plate should be inspected regularly as part of routine machine maintenance, particularly after heavy-duty grinding sessions on abrasive concrete or surface coating removal applications. Using a genuine OEM replacement ensures correct fitment, proper tooling alignment, and full compatibility with Bartell's planetary drive assembly.
Genuine Bartell Global OEM part, sold by an authorized dealer.
