In stock and ready to ship.
This burner control kit includes a replacement burner controller, 20-gauge wiring, and installation instructions for servicing the burner assembly on Wacker Neuson hydronic and ground heaters. Mounted in the burner cpl. assembly, the controller manages ignition sequencing, flame sensing, fuel shutoff valve operation, and burner motor control, forming the core of the diesel or gas combustion safety circuit.
Wacker Neuson wiring diagrams for compatible models show the burner control connected through a seven-pin connector to the main control panel terminal strip, with dedicated terminals for ignition, limit, burner valve, alarm, and cadmium cell flame sensor inputs. The 20-gauge wire included in this kit matches the gauge specified in the factory burner cable and pigtail cable runs between the burner and main panel. Installation instructions are included to guide correct terminal-by-terminal reconnection during burner control replacement.
This kit is suited for diesel burner configurations and addresses failures such as lockout conditions, ignition faults, or wiring degradation in the burner circuit. Replacing the control module and associated wiring as a matched kit helps ensure the new controller operates with correct wire ratings throughout the circuit.
Compatible with the following Wacker Neuson models:
- E 2200
- E 3000
- E 5000
- E1100
- E1250B
- E1250P
- E1250S
- E12540B
- E3000ES
- Pureheat
Genuine Wacker Neuson OEM part, sold by an authorized dealer.
